Rates | Day | Week | Month |
---|---|---|---|
Regular |
$350 | $1,475 | $4,200 |
Corporate |
$330 | $1,350 | $3,650 |
Emission Rating | Interim Tier 4 / EU Stage 3B |
Engine Make / Engine Model | Yanmar / 4 TNV 88 |
Net Power, kW (hp) @ Rated rpm | 28.4 (38.1) @ 2400 |
Gross Power, kW (hp) | not published |
Displacement, L (cu in) | 2.19 (134) |
Pump Type | Variable Displacement + Gear |
Total Pump Flow, L/m (gpm) | 124.9 (33) |
Normal Relief Pressure, kPa (psi) | not published |
Auxilliary Hyd. Max Flow Rate, L/m (gpm) | 85.2 (22.5) |
Track Width, mm (in) | 406 (16) |
Overall Track Length, mm (ft) | 2500 (8 ' 2 '') |
Ground Clearance, mm (in) | 340 (13.4) |
Width Over Std Track, mm (ft) | 2000 (6 ' 7 '') |
Ground Pressure, Std. Track, kPa (psi) | 28 (4.06) |
Travel speed 1, kph (mph) | 2.6 (1.7) |
Travel speed 2, kph (mph) | 4.2 (2.7) |
Travel speed 3, kph (mph) | not published |
Travel speed 4, kph (mph) | not published |
Gradeability, % | --- |
Gradeability, deg | --- |
Max. Drawbar Pull, kN (lbf) | not published |
Blade Width, mm (ft) | 2000 (6 ' 7 '') |
Blade Height, mm (ft) | 430 (17) |
Blade Max Lift Above Grd. Level, mm (in) | 430 (16.9) |
Blade Max Lift Below Grd. Level, mm (in) | 335 (13.2) |
Standard Arm, mm (ft in) | 1380 (4 ' 6 '') |
Max. Digging Height w/Std Arm, mm (ft) | 5760 (18 ' 11 '') |
Max. Digging Depth w/Std Arm, mm (ft) | 3550 (11 ' 8 '') |
Max. Digging Reach w/Std Arm, mm (ft) | 5940 (19 ' 6 '') |
Max. Digging Reach @ G.L. w/Std Arm, mm (ft) | not published |
Max. Dump Height w/Std Arm, mm (ft) | 4100 (13 ' 5 '') |
Max. Vertical Wall Depth w/Std Arm, mm (ft) | not published |
Min. Front Swing Radius, mm (ft in) | 2150 (7 ' 1 '') |
Min Front Swing Radius w/Boom Swing, mm (ft) | --- |
Boom Swing Angle - left, deg | 80 |
Boom Swing Angle - right, deg | 60 |
Lift Cap. Over Front @ 10' G.L. (incl bckt), kg (lb) | 2387 (5258) |
Lift Cap. Over Side @ 10' G.L. (incl bckt), kg (lb) | 1045 (2301) |
Max Arm Digging Force, kN (lb | 24 (5401) |
Max Bucket Digging Force, kN (lb) | 36.8 (8273) |
Tail Swing Radius, mm (ft in) | 1000 (3 ' 3 '') |
Swing Speed, rpm | 9.0 |
Transport Length, mm (ft) | 5460 (17 ' 11 '') |
Transport Height, mm (ft) | 2510 (8 ' 3 '') |
Transport Width, mm (ft) | 2000 (6 ' 7 '') |
Fuel Tank, L (gal) | 70 (18.5) |
Hydraulic Reservoir, L (gal) | 50 (13.2) |
SAE Operating Weight, kg (lb) | 4904 (10811) |
