Rates | Day | Week | Month |
---|---|---|---|
Regular
|
$600 | $2,500 |
$8,500
|
Corporate
|
$575 | $2,450 |
$8,400
|
Transport Length Mono Boom, mm (ft/in) | 7710 (25 ft 4 in) |
Transport Height - Maximum, mm (ft/in) | 2870 (9 ft 5 in) |
Overall Undercarriage Width, mm (ft/in) | 2690 (8 ft 10 in) |
Track Length On Ground, mm (ft/in) | 2880 (9 ft 5 in) |
Overall Undercarriage Length, mm (ft/in) | 3580 (11 ft 9 in) |
Tailswing Radius, mm (ft/in) | 2190 (7 ft 2 in) |
Ground Clearance, mm (inches) | 410 (16) |
Width over fixed tracks, mm (ft/in) | 2690 (8 ft 10 in) |
Track Gauge, mm (ft/in) | 1990 (6 ft 6 in) |
Digging Reach - Mono Boom, mm (ft/in) | 8770 (28 ft 9 in) |
Ground Level Reach - Mono Boom, mm (ft/in) | 8670 (28 ft 5 in) |
Dig Height - Mono Boom, mm (ft/in) | 8930 (29 ft 4 in) |
Dump Height - Mono Boom, mm (ft/in) | 6520 (21 ft 5 in) |
Dig depth - 2.44m / 8'ft flat bottom, mm (ft/in) | 5880 (19 ft 3 in) |
Dig Depth - Mono Boom, mm (ft/in) | 6030 (19 ft 9 in) |
Standard Dipper, mm (ft/in) | 3010 (9 ft 11 in) |
Fuel Tank, ltr (gallons (US)) | 285 (75.3) |
Hydraulic Tank, ltr (gallons (US)) | 69 (18.2) |
Number Of Batteries | 2 |
Voltage, V | 24 |
Ground Bearing Pressure, kPa (PSI) | 32 (4.64) |
Swing Speed, rpm | 13.3 |
Swing Torque, kNm (lbf / ft) | 34 (25000) |
Travel Speed - High, kph (mph) | 5.5 (3.4) |
Tractive Force, kN (lbf) | 110 (24729) |
Dipper Tearout, kN (lbf) | 60 (13521) |
Bucket Breakout, kN (lbf) | 96 (21480) |
Gradeability, % | 70 |
Total Flow, lt/min (gallons (US) / min) | 210 (56) |
Bucket Pressure, bar (PSI) | 343 (4980) |
Boost Pressure, bar (PSI) | 363 (5265) |
Operating Weight, kg (lbs) | 13407 (29531) |
