Rates | Day | Week | Month |
---|---|---|---|
Regular |
$1,275 | $5,100 | $15,300 |
Corporate |
$1,211 | $4,845 | $14,535 |
Height - Max, mm (ft/in) | 3138 (10 ft 4 in) |
Ground Clearance, mm (inches) | 387 (15.2) |
Track Length - On Ground, mm (ft/in) | 2615 (8 ft 7 in) |
Length - PAT Blade Straight, mm (ft/in) | 4906 (16 ft 1 in) |
Track Gauge, mm (ft/in) | 1981 (6 ft 6 in) |
Blade - Width, mm (ft/in) | 3077 (10 ft 1 in) |
Blade - Dig Depth, mm (inches) | 536 (21) |
Blade - Tilt, mm (ft/in) | 426 (1 ft 5 in) |
Steering - Differential | No |
Fuel Tank, ltr (gallons (US)) | 262 (69.2) |
Blade - Capacity, m³ (yd³) | 3.6 (4.8) |
Speed - Forward Maximum, kph (mph) | 8.9 (5.5) |
Speed - Reverse Maximum, kph (mph) | 8.9 (5.5) |
Ground Bearing Pressure, kPa (PSI) | 32.1 (4.66) |
Implement Pump - Type | Gear |
Implement Pump - Flow, lt/min (gallons (US) / min) | 95 (25) |
Implement Pump - Pressure, bar (PSI) | 220.63 (3200) |
Operating Weight, kg (lbs) | 14489 (31943) |
