Rates | Day | Week | Month |
---|---|---|---|
Regular |
$875 | $3,500 | $10,500 |
Corporate |
$831 | $3,325 | $9,975 |
Height - Max, mm (ft/in) | 2799 (9 ft 2 in) |
Ground Clearance, mm (inches) | 329 (13) |
Track Length - On Ground, mm (ft/in) | 2184 (7 ft 2 in) |
Length - PAT Blade Straight, mm (ft/in) | 4016 (13 ft 2 in) |
Track Gauge, mm (ft/in) | 1448 (4 ft 9 in) |
Blade - Width, mm (ft/in) | 2464 (8 ft 1 in) |
Blade - Dig Depth, mm (inches) | 528 (20.8) |
Blade - Tilt, mm (ft/in) | 338 (1 ft 1 in) |
Steering - Differential | No |
Fuel Tank, ltr (gallons (US)) | 202 (53.45) |
Hydraulic Tank, ltr (gallons (US)) | 100 (26.42) |
Blade - Capacity, m³ (yd³) | 1.6 (2.1) |
Speed - Forward Maximum, kph (mph) | 8 (5) |
Speed - Reverse Maximum, kph (mph) | 8 (5) |
Ground Bearing Pressure, kPa (PSI) | 43.9 (6.4) |
Implement Pump - Type | Gear |
Implement Pump - Flow, lt/min (gallons (US) / min) | 80 (21) |
Implement Pump - Pressure, bar (PSI) | 206.84 (3000) |
Operating Weight, kg (lbs) | 7959 (17510) |
