Rates | Day | Week | Month |
---|---|---|---|
Regular |
$340 | $1,300 | $3,600 |
Corporate |
$325 | $1,275 | $3,370 |
Emission Rating | Interim Tier 4 / EU Stage 3B |
Engine Make / Engine Model | John Deere / PowerTech 4024T |
Net Power, kW (hp) @ Rated rpm | 33.5 (45) @ 2400 |
Gross Power, kW (hp) | 36.5 (49) |
Net Peak Torque, N-m (lb-ft) | not published |
Displacement, L (cu in) | 2.4 (149) |
Engine Aspiration | Turbo. |
Fuel Capacity, L (gal) | 66 (17.5) |
Standard Pump Flow, L/min (gpm) | 61 (16) |
Optional High Flow, L/min (gpm) | not published |
System Pressure, kPa (psi) | 23800 (3450) |
Hydraulic power, kW (hp) | 26.1 (35) |
Optional high flow hydraulic power, kW (hp) | not published |
SAE Rated Operating Capacity, kg (lb) | 681 (1500) |
Tipping Load, standard, kg (lb) | 2003 (4412) |
Breakout Force Boom, kN (lb) | 12 (2700) |
Breakout Force Bucket, kN (lb) | 14.7 (3300) |
Vertical lift geometry | No |
Maximum Ground Speed, standard, kph (mph) | 9.7 (6) |
Two Speed Transmission Ground Speed, kph (mph) | not published |
Standard Rubber Track Width mm (in) | 320 (12.6) |
Ground Pressure, Standard Track, kPa (psi) | 33.3 (4.8) |
Track Guage, center to center, mm (in) | 1220 (48.4) |
Length with Bucket, mm (in) | 3170 (124) |
Length Without Bucket, mm (in) | 2440 (96) |
Width Without Bucket, mm (in) | 1540 (61) |
Height to ROPS, mm (in) | 1960 (77) |
Height to Hinge Pin, mm (in) | 2780 (110) |
Dump Height, mm (in) | 2310 (91) |
Dump Reach, mm (in) | 442 (17.4) |
Dump Angle, degrees | 40 |
Bucket Rollback @ ground, degrees | 30 |
Ground Clearance, mm (in) | 198 (7.8) |
Angle of Departure, degrees | 25.25 |
SAE Operating Weight, kg (lb) | 3087 (6800) |
