Rates | Day | Week | Month |
---|---|---|---|
Regular |
$350 | $1,400 | $3,900 |
Corporate |
$335 | $1,300 | $3,430 |
Emission Rating | Interim Tier 4 / EU Stage 3B |
Engine Make / Engine Model | John Deere / PowerTech E 4024HT |
Net Power, kW (hp) @ Rated rpm | 47.1 (63) @ 2300 |
Gross Power, kW (hp) | 50.8 (68) |
Net Peak Torque, N-m (lb-ft) | 230 (170) |
Displacement, L (cu in) | 2.4 (149) |
Engine Aspiration | Turbo. intercooled |
Fuel Capacity, L (gal) | 70 (90) |
Standard Pump Flow, L/min (gpm) | 59 (15.5) |
Optional High Flow, L/min (gpm) | not published |
System Pressure, kPa (psi) | 21370 (3100) |
Hydraulic power, kW (hp) | 22.4 (30) |
Optional high flow hydraulic power, kW (hp) | not published |
SAE Rated Operating Capacity, kg (lb) | 863 (1900) |
Tipping Load, standard, kg (lb) | 2542 (5600) |
Breakout Force Boom, kN (lb) | 15.8 (3500) |
Breakout Force Bucket, kN (lb) | 23.2 (5125) |
Vertical lift geometry | Yes |
Maximum Ground Speed, standard, kph (mph) | 9.8 (6.1) |
Two Speed Transmission Ground Speed, kph (mph) | not published |
Standard Rubber Track Width mm (in) | 320 (21.6) |
Ground Pressure, Standard Track, kPa (psi) | 37.2 (5.4) |
Track Guage, center to center, mm (in) | 1500 (59.1) |
Length with Bucket, mm (in) | 3360 (132) |
Length Without Bucket, mm (in) | 2740 (108) |
Width Without Bucket, mm (in) | 1820 (72) |
Height to ROPS, mm (in) | 2000 (79) |
Height to Hinge Pin, mm (in) | 3000 (118) |
Dump Height, mm (in) | 2400 (95) |
Dump Reach, mm (in) | not published |
Dump Angle, degrees | 42 |
Bucket Rollback @ ground, degrees | 32 |
Ground Clearance, mm (in) | 250 (9.8) |
Angle of Departure, degrees | 25 |
SAE Operating Weight, kg (lb) | 3882 (8550) |
